DC Axial Fans - 12038MA-48R-EE-00
Get a sample
Distributor |
Availability |
|
|---|---|---|
Distributor Newark element 14 |
Availability 70 |
|
Distributor Digi-Key Electronics |
Availability 79 |
Specification Sheet |
Category |
DC Axial Fans |
Part Number |
12038MA-48R-EE-00 |
Bearing Type
|
Ball Bearing
|
COO
|
China
|
Current
[A]
|
0.82
|
Fan Speed
[RPM]
|
9000
|
Frame Depth
[mm]
|
38
|
Frame Height (mm)
|
120
|
Frame Width (mm)
|
120
|
Input Power
[W]
|
39.4
|
Life Expectancy L10
|
40 degree C 40,000 Hours
|
Mass (g)
|
580
|
Max. Air Flow
[CFM]
|
186
|
Max. Air Flow
[m3 per min]
|
5.25
|
Max. Static Pressure
[In H2O]
|
3
|
Max. Static Pressure
[Pa]
|
740
|
Production Status
|
Active
|
Noise
[dB]
|
72
|
Nominal Voltage
[V]
|
48
|
Operating Voltage - Lower (V)
|
38
|
Operating Voltage - Upper (V)
|
60
|
Rib/Flange
|
Flange
|
Series Frame Width
[mm]
|
120
|
Tach / Locked Rotor Output
|
Standard 2 Wire
|
